NOTES:

Part #	Number on image	Usage Notes
411-322-050	42	C/W Nyloc Nut

718 - Stealth Original FM 340 - Drive System

Stealth Original FM 340

Grouped product items
No.	Product Name	Price
1	PTO Complete Driveshaft - 540/1000rpm - Trimax Specification 406-340-870 More Info >	$589.47
2	Bolt - Hex Head - M8 x 16 - Trimax Specification 301-208-163 More Info >	$0.61
3	Washer - Flat 308-080-016 More Info >	$0.12
4	Cone 410-440-400 More Info >	$30.44
5	Gearbox - Standard Rotation - 540rpm 405-200-720 More Info >	$1,712.00
6	Gearbox 405-200-725 More Info >	$2,669.37
7	Gearbox - Breather 405-207-207 More Info >	$34.36
8	Blanking Plug - M12 209-900-012 More Info >	$0.45
9	Key - Gearbox 405-207-154 More Info >	$16.27
10	Bolt - Hex Head - M12 x 30 - Trimax Specification 301-212-303 More Info >	$2.36
11	Washer - Spring M12 - Trimax Specification - 308-120-043 More Info >	$0.45
12	Pulley - Taper Lock 403-361-270 More Info >	$224.52
13	Bush - Taper Lock 402-060-680 More Info >	$83.73
14	Bolt - Hex Head - M8 x 20 - Trimax Specification 301-208-203 More Info >	$0.90
15	Retainer Ring 402-060-450 More Info >	$17.30
16	Bush 402-060-320 More Info >	$30.58
17	Pulley 403-360-300 More Info >	$80.25
18	Bolt - Hex Head - M8 x 40 - Trimax Specification 301-208-403 More Info >	$1.28
19	Vee Belt - Trimax Specification 404-040-830 More Info >	$50.00
20	Vee Belt - Trimax Specification 404-041-300 More Info >	$78.11
21	Nut - Half 307-212-023 More Info >	$1.13
22	Belt Retainer Guide 417-330-450 More Info >	$11.82
23	Pulley Assembly - Idler 403-360-111 More Info >	$112.40
24	Washer - Flat 108-071-413 More Info >	$2.88
25	Stud 403-330-443 More Info >	$0.90
26	Nut - Plain M12 - Trimax Specification - 307-212-013 More Info >	$0.57
27	Washer - Flat M12 - Trimax Specification - 308-120-013 More Info >	$0.45
28	Washer - Heavy Flat 308-120-063 More Info >	$1.84
29	Bolt - Hex Head - M12 x 45 - Trimax Specification 301-212-453 More Info >	$3.04
30	Idler Tower Incl Base 403-330-442 More Info >	$88.29
31	Idler Tower Incl Base 403-330-432 More Info >	$71.54
32	Idler Tower Incl Base 403-330-423 More Info >	$53.03
33	Idler Tower Incl Base 403-330-424 More Info >	$89.27
34	Spindle Assembly - Type 5a Ext 50mm 504-328-042 More Info >	$985.52
35	Spindle Assembly - Type 5b Short Ext 50mm 504-328-043 More Info >	$985.52
36	Nut - Flange 450-000-078 More Info >	$3.85
37	Bolt - Hex Head - M12 x 50 - Trimax Specification 301-212-503 More Info >	$3.16
38	Washer - Hardened 108-071-513 More Info >	$4.58
39	Disc Anti-scalp Rotating - E Type 4 Stud 503-325-475 More Info >	$337.90
40	Blade Beam - LazerBladez 411-322-762 More Info >	$101.65
41	Blade - LazerBlade Uplift - Uplift Profile Rotary Cutting Blade 411-160-842 More Info >	$10.70
42	Blade Bolt - With M12 Nyloc Nut - LazerBlade and NexaBlade Mounting i See notes section for usage notes on this part 411-322-050 More Info >	$6.50
43	Nut - Nyloc M12 - Trimax Specification - 307-212-053 More Info >	$0.67
44	Clamp Plate - LazerBladez 411-322-820 More Info >	$37.45
