NOTES:

Part #	Number on image	Usage Notes
407-329-090	6	Spindles shims available in various thickness part numbers listed below, use as required 407-329-090 - Shim - Spindle Bearing 0.01mm 407-329-091 - Shim - Spindle Bearing 0.05mm 407-329-092 - Shim - Spindle Bearing 0.08mm 407-329-093 - Shim - Spindle Bearing 0.12mm

757 - Topper S3 - 237 - Spindle Assembly

Topper S3 237

Grouped product items
No.	Product Name	Price
	Spindle Assembly - Topper S3 504-328-012 More Info >	$1,148.84
1	Grease Nipple 208-442-550 More Info >	$3.06
2	Bearing 401-021-650 More Info >	$66.50
3	Lock Nut 401-021-750 More Info >	$13.59
4	Tube - Spindle Spacer 402-329-081 More Info >	$33.07
6	Shim i See notes section for usage notes on this part 407-329-090 More Info >	$3.10
7	Cap - Spindle Type 4/5/5a/6e 407-329-000 More Info >	$21.61
8	Cap - Spindle Type 5a and 6e 407-329-001 More Info >	$18.19
9	Housing - Spindle 407-329-031 More Info >	$423.31
10	Wheel Stud 450-000-066 More Info >	$14.98
